Mitutoyo Micrometer Head XY-Stage, Thimble 49mm 0-25mm, X-Axis

These XY Stage type micrometer heads let you read measurement values easily.
They offer the following benefits:

• Micrometer heads especially designed for accurate cross-travel stage translation in X and Y axes.
• Spindle end: Flat form and hardened, or spherical with carbide tip (more than HRA90), lapped surface.

Mitutoyo Prod. No.: 152-390

Range:	0 - 25 mm
Maximum Permissible Error J MPE:	±2 µm
Spindle end:	Flat with non-rotating device
Spindle pitch:	1 mm
Stem:	Plain
Stem Ø:	18 mm
Special features:	For X-axis Bidirectional grad.
Mass:	270 g
Measuring face:	Hardened steel (>60HRC)
Digital/Analog:	Analog
Inch-Metric:	Metric
Graduation:	0.005 mm
