Available in the following magnifications: 2x, 4x, 8x, 10x or 15x. See above for details.
A real all-rounder: the head of the magnifying glass can be tilted and easily changed with a clever click-on, click-off function. Changeable Heads can also be purchased individually.
Features:
Fitted with an aplanatic, respectively a bifocal or an aspherical lens system (for the lower magnifications), the LED hand-held magnifier MODULAR mobile fulfills highest optical requirements. The optics are made from silicate glass, which is very scratch-resistant, has a very high resolution (very sharp!) and produces an extremely high contrast image. Schweizer uses a UV absorbent optical crown as used with prescription lenses (refractive index n=1.52).
The housing is coated with a special 2-component-coating, which is very scratch-resistant. Additionally, this coating is resistant to hand perspiration and nearly all chemicals and solvents. A long-life high-performance LED with a lighting color of approximately 6000K completes this magnifier.
| Art.nr. |
Magnification | Lens dimensions Ø | Lens type |
| 1992019; 1992015; 19920110 | 2x/4x | 70mm/22mm | bifocal |
| 1904019; 1904015; 19040110 | 4x | 55.0mm | aspheric |
| 1908019; 1908015; 19080110 | 8x | 30.0mm | aplanatic |
| 1910019; 1910015; 19100110 | 10x | 22.8mm | aplanatic |
| 1915019; 1915015; 19150110 | 15x | 16.3mm | aplanatic |
High Professional Product Made in Germany
- LED
High performance LED 4500K - Housing/Casing
Shock resistant
Resistant to hand perspiration
Resistant to chemical/solvents
Scratch resistant two-component coating - Lens/Optics
Aplanatic lens-system
Aspheric lens (4x)
Scratch resistant
High resolution (very high sharpness)
High contrast image - Magnification
2x, 4x, 8x, 10x or 15x
Tech-Line is synonymous with technically demanding products which meet the requirements for high-quality optics, ergonomic handling and sturdy materials which are suitable for daily use.
Discover the variety
By developing the Tech-Line Series, SCHWEIZER created an ultra-modern magnifier generation, which combines the following features.
The Tech-Line Series has been professionally adapted for the demanding requirements & conditions of any work environment.
Additional performance:
- High quality, aplanatic silicate glass optics. In the low magnification range, biconvex optics / bifocals are used.
- The silicate-glass optics used in Schweizers Tech-Line magnifiers are 100% manufactured in Germany. Not only do they contain the best optical features, they are also very scratch-resistant! (especially in comparison with plastic lenses).
- All magnifiers with a silver coating are coated with a special 2-component-coating:
Resistant to hand perspiration.
Resistant to nearly all solvents/chemicals.
Very hard and plane surface, scratch-resistant and easy to clean. - Schweizer uses environmentally-friendly, energy-saving and extremely long-life high-performance LEDs
